The Pendleton (A)

Plan #:
Plan #:

*garage level excludes stair area


The Pendleton A and B remain our most popular carriage house designs and have been featured in Country Living Magazine. Both models have identical floor plans but different balcony options.

The second floor apartment features an open, airy living-dining area with cathedral ceiling.

The efficient kitchen has a walk-in pantry and convenient pass-through counter to the dining area.

A spacious bedroom includes a walk-in closet. A full bath with laundry closet completes the second floor.

French doors from the bedroom and living-dining area open to a balcony providing space to enjoy nature and outdoor views.

Distinctive exterior features include a standing-seam metal roof and horizontal siding.

A large two-car garage offers enough space for a workbench and storage…and who doesn't need a workbench and a little more storage?

PDF Reproducible Set – You will receive one full set of construction drawings in PDF format. A PDF Reproducible Set provides a license to print unlimited copies you may need for bid requests, the builder, local building officials, and yourself. This is a license for the purchaser to build ONE house.


CAD File – You will receive one full set of construction drawings in AutoCAD format. This allows a design professional to make modifications in AutoCAD compatible software. Please consult a design professional before purchasing. A complimentary PDF will be included with a CAD File purchase. This is a license for the purchaser to build ONE house.


Multi-use License – If you are a builder and would like a Multi-use License to build one of our homes more than once, please contact us at

Office phone: 540-341-8850 Monday-Friday 8:30-5:30 EST


Our plans may not be returned for credit or refund under any circumstances once the order has been processed. Please double check your selection carefully before placing your order and talk to a design professional if needed. It is also very important that you check the dimensions of your lot taking into account the zoning/building restriction lines (setbacks) before placing your order.

The Pendleton (A) Plans (CAD)

A complimentary PDF is included with CAD file

The Pendleton (A) Plans (PDF)
